Pleaide flat sheet membranesupplier page

Logo The Mbr Site
Supplied by: Alsys Group
Flat Sheet (FS) MBR membrane configuration | Polymeric membrane material

Module product series:

  • Pleaide UF and MF

About Pleaide flat sheet membrane

Flat sheet polymeric membranes in a plate and frame configuration for use external to the MBR. The membrane on each plate may be isolated from the others. The plates are easily disassembled in order to permit mechanical cleaning if necessary due to a process upset or other reasons.

  • Membrane area per unit floor area: 20.1 m2/m2 (based on a membrane rack including piping header)
  • Membrane module height (m): 1.2 m (heights given are based on the membrane module).

(Dimensions for guidance only and may change − please confirm with supplier.)

Flat Sheet (FS) MBR membrane configuration
Polymeric membrane material | PAN or PVDF
Pore size: 30 nm for PAN | 100 and 200 nm for PVDF
Packing density: Module membrane area per unit module volume 45 m2/m3

Module product series:

  • Pleaide UF and MF

MBR Case studies and specifications

Company summary

Head office in USA
Operates in Americas
MBRs: 21 commissioned plants | Total installed capacity of 5045 m3/day
